Ingco True RMS DC/AC Clamp Meter – 6000 Counts Digital Clamp Multimeter DCM66002

Perform safe, accurate, and efficient electrical measurements with the Ingco DCM66002 True RMS DC/AC Clamp Meter. Designed for electricians, maintenance engineers, HVAC technicians, industrial professionals, and advanced DIY users, this professional clamp meter allows you to measure current without disconnecting wires, making electrical inspections faster and safer.

Equipped with a True RMS 6000-count display, the DCM66002 delivers highly accurate readings for both sinusoidal and non-linear electrical signals. It measures DC/AC current up to 600A, DC/AC voltage up to 600V, resistance, capacitance, frequency, and temperature, making it a versatile diagnostic tool for residential, commercial, and industrial electrical systems.

The integrated Non-Contact Voltage (NCV) detector enables users to identify live conductors without direct contact, improving safety during troubleshooting and maintenance. Whether you're inspecting electrical panels, servicing motors, diagnosing HVAC systems, or testing industrial equipment, this clamp meter provides reliable performance with the convenience of a compact, ergonomic design. Built for demanding environments, it is an essential instrument for professionals who require precision and efficiency in every measurement.

Key Features & Specifications

• True RMS 6000-Count Display: Provides accurate measurements for AC and DC electrical systems, including non-linear loads.
• 600A DC/AC Current Measurement: Measures current safely without disconnecting live conductors using the clamp jaw.
• Comprehensive Multi-Function Testing: Measures voltage, resistance, capacitance, frequency, temperature, and current in one device.
• Integrated NCV Detection: Identifies live voltage without direct contact, improving user safety during inspections.
• Wide Temperature Measurement: Measures temperatures from -40°C to 1000°C (-40°F to 1832°F) for electrical and HVAC diagnostics.
• Professional Portable Design: Compact, ergonomic construction suitable for field service, maintenance, and industrial applications.

Technical Specifications

• Brand: Ingco
• Model: DCM66002
• Product Type: DC/AC Clamp Meter
• Display: True RMS 6000 Counts

DC/AC Current

• 60A
• 600A

DC/AC Voltage

• 600mV
• 6V
• 60V
• 600V

Resistance

• 600Ω
• 6kΩ
• 60kΩ
• 600kΩ
• 6MΩ
• 60MΩ

Capacitance

• 10nF
• 100nF
• 1000nF
• 10µF
• 1000µF
• 10mF
• 100mF

Frequency

• 10Hz
• 100Hz
• 1000Hz
• 10kHz
• 100kHz
• 1000kHz
• 10MHz

Temperature

• -40°C to 1000°C
• -40°F to 1832°F

Additional Features

• NCV (Non-Contact Voltage Detection)

Product Highlight

Measure with confidence using professional accuracy built for every electrical challenge.
